PAM8403 Class D 2x3W Amplifier Board HW-104 - CAP. KECIL

Referensi T142

READY CAP KECIL

Stok 810

Rp. 4.000

PAM8403 Class D 2x3W Amplifier Board HW-104 - CAP. KECIL

Introduction:

PAM8403 Mini Class D digital amplifier board

1. Working voltage: 2.5V-5.5V. Note: The power supply voltage should not exceed 5.5V, the power of positive and negative do not reversed.

2. Equipped with speaker: 4-8 Europe, recommended: 4 ohms; Speaker power: 2-8W.

3. You can use the computer USB port 5V power supply, or use the phone charger USB port 5V power supply, you can also use lithium battery power.

4. High efficiency of 90%, and 5V power at 4Ω load conditions, can provide 3W (left channel) + 3W (right channel) output power. Efficiency amplifier Class A, Class B, etc. is only about 30% of the Class D amplifier respected in today's green trend.

5.D high class amplifier efficiency, temperature rise will not affect the sound quality, but without additional heat sink, taking up very small.

6. The amplifier circuit board built-in noise cancellation, no-pop noise power on / off; module has short circuit current protection and over-temperature protection.

7. The board size: 21 * 19 (mm)

Application:

LCD televisions, monitors

laptop

Portable speakers

Portable DVD players, game consoles

Phone / speakerphone
