MJE13007A MJE13007 MJE 13007A 13007 NPN Transistor TO-220

MJE13007A MJE13007 MJE 13007A 13007 NPN Transistor TO-220

Type Designator: MJE13007A

Material of Transistor: Si

Polarity: NPN

Maximum Collector Power Dissipation (Pc): 40 W

Maximum Collector-Base Voltage |Vcb|: 700 V

Maximum Collector-Emitter Voltage |Vce|: 400 V

Maximum Emitter-Base Voltage |Veb|: 9 V

Maximum Collector Current |Ic max|: 8 A

Max. Operating Junction Temperature (Tj): 150 °C

Transition Frequency (ft): 4 MHz

Collector Capacitance (Cc): 110 pF

Forward Current Transfer Ratio (hFE), MIN: 8

Noise Figure, dB: -
